Category: JKR SIGNAGE (REAM) · Material: ACP · Size: 1200 x 900 · Spec: JKR · Thickness: 3.0MM · Type: A SHAPE / POST

What this sign says

A symbol board with no wording on the face, supplied ready mounted on an A frame stand. It carries two black lines inside a yellow diamond on fluorescent orange, the left line bending in toward the right, with a white distance plate below. It tells drivers the carriageway narrows from the left, so traffic keeps right before reaching the works.

When it is used

  • Left lane or left shoulder work where the running width drops.
  • Trenching, drain and kerb work along the left verge.
  • Resurfacing with the near side coned off.
  • Short duration works where a free standing board is quicker than a post.

Before you order

  • Our face is 1200 x 900 on 3.0MM ACP. That is our stock size, not a figure taken from the standard, so check it against your traffic management plan.
  • This one comes on the A frame, so it stands on the surface without digging in. Useful where the job moves along the road day by day.
  • The standard gives its road narrow sign a distance range of 100 m to 1400 m (ATJ 2C/85, Part Two). Fix the setback in your traffic management plan, then tell us the figure for the plate.
  • Order cones with it. Guidance cones run at 15 m spacing within the traffic control zone, and super cones at 5 m through the taper (ATJ 2C/85, 2.3.2.1(b) and 2.3.2.2(a)).
  • Tell us the frame you want (A shape or post), how many boards, your start date, how long you need them, and whether we deliver or you collect from the Bangi yard.
